Icod.Terminal

Icod.Terminal is the managed, cross-platform live-terminal layer for the Icod library family. It is intended to sit between Icod.TermInfo and higher-level consumers such as Icod.DCurses, terminal-aware command-line tools, monitors, editors, pagers, and REPLs.

Status

0.3.0 is the current stable release line. It retains the 0.1 live-session foundation and 0.2 rich-input contract while adding bounded, expectation-driven active terminal queries over the same session-owned input path.

The stable 0.3 API includes typed Primary and Secondary Device Attributes, Device Status Report, Cursor Position Report, DECRQSS status-string queries, and XTGETTCAP live capability observations. Session opening remains passive: active interrogation occurs only when a caller explicitly invokes a query method.

The first functional milestone remains intact: watch, slabtop, and top operate through Icod.DCurses over the shared Icod.Terminal / Icod.TermInfo stack.

Architecture

Icod.TermInfo
      ^
      |
Icod.Terminal
      ^
      |
Icod.DCurses
      ^
      |
watch / slabtop / top

Icod.TermInfo remains the immutable terminal-capability authority. Icod.Terminal owns live endpoint observation, terminal modes, input, dimensions, lifecycle, terminal identity, output setup, and reversible presentation-state mechanisms. Icod.DCurses owns cells, windows, virtual-screen state, and refresh/diff policy. A future Icod.Pty package remains an adjacent concern rather than a prerequisite.

Icod.Timing supplies the monotonic elapsed-time and cancellable-delay primitives used by Terminal's relative event timeouts and Escape-sequence ambiguity windows.

Installation

The stable 0.3 release installs as:

dotnet add package Icod.Terminal --version 0.3.0

The package targets net8.0, net9.0, and net10.0 and depends on Icod.TermInfo 1.4.1 and Icod.Timing 1.0.0.

Quick start

The ordinary application entry point is TerminalSession:

using Icod.Terminal;

await using TerminalSession session = await TerminalSession.OpenAsync(
    new TerminalSessionOptions {
        InputMode = TerminalInputMode.CBreak,
        EchoInput = false
    }
);

TerminalEvent terminalEvent = await session.ReadEventAsync(
    TimeSpan.FromSeconds( 1 )
);

The session borrows process-standard endpoints, owns only the terminal state transitions it applies, and restores its captured baseline during DisposeAsync().

Applications which genuinely need complete native mode observation, serialization, or custom endpoint/control backends may use the lower-level public contracts; ordinary interactive applications should prefer TerminalSession.

0.2 rich input

Rich input remains on the same TerminalSession.ReadEventAsync path. Reporting protocols are enabled only through reversible session-owned leases:

TerminalControlResult<TerminalInputProtocolLease> protocolResult =
    await session.AcquireInputProtocolsAsync(
        new TerminalInputProtocolOptions {
            BracketedPaste = true,
            FocusReporting = true,
            MouseTrackingMode = TerminalMouseTrackingMode.ButtonEvents
        }
    );

if ( protocolResult.IsAvailable ) {
    await using TerminalInputProtocolLease protocols =
        protocolResult.GetRequiredValue();

    TerminalEvent terminalEvent = await session.ReadEventAsync();
    TerminalInputEvent? input = terminalEvent.Input;

    if ( TerminalInputEventKind.Mouse == input?.Kind ) {
        TerminalMouseEvent mouse = input.Mouse!;
        // mouse.Column and mouse.Row are zero-based terminal-cell coordinates.
    }
}

The lease owns only the requested terminal reporting protocols. Nested leases are supported; the last relevant lease restores the prior protocol state, and session disposal remains authoritative cleanup.

Bracketed paste is framed rather than accumulated as one unbounded string: applications receive Begin, one or more bounded Data events, then End. Paste Data chunk boundaries are transport/decoder boundaries and are not semantic line boundaries.

Decoder policy is configured per session:

new TerminalSessionOptions {
    InputDecoderOptions = new TerminalInputDecoderOptions {
        EscapeSequenceTimeout = TimeSpan.FromMilliseconds( 50 ),
        MaximumBufferedBytes = TerminalSession.MaximumBufferedInputBytes,
        PasteChunkBytes = 4096
    }
};

The defaults preserve the 0.1 Escape-ambiguity and buffer policy. Modified traditional navigation/editing/function-key sequences normalize into TerminalKey plus TerminalKeyModifiers; no second keyboard protocol is required.

The reviewed 0.2 additions are recorded in docs/Public-API-Baseline-0.2.md.

0.1 consumer contract

The T12B audit found no breaking public-API correction required before 0.1.0. The reviewed behavior and API surface are recorded in:

• docs/T12B-Public-API-and-Consumer-Contract.md;
• docs/Public-API-Baseline-0.1.md.

Important 0.1.x rules include:

• input is always an interactive terminal; output may be redirected only when explicitly permitted;
• canonical/cbreak/raw are semantic requests mapped separately to POSIX and Windows host models;
• unknown POSIX terminal names fall back safely rather than silently becoming xterm;
• input decoding is incremental and the Escape-prefix ambiguity window is bounded;
• Available, Unavailable, Unsupported, and Failed remain distinct low-level outcomes;
• session cleanup restores captured state and does not close borrowed caller/process endpoints;
• PTY/ConPTY creation and child-process hosting belong to a future adjacent Icod.Pty package.

The 0.1.x runtime dependencies are Icod.TermInfo 1.0.0 and Icod.Timing 1.0.0. Icod.DCurses and Icod.ProcPs are consumers, not runtime dependencies of this package.

Target frameworks

The library targets:

• net8.0;
• net9.0;
• net10.0.

The codebase uses C# 13 and supports the terminal-control implementations provided for Windows, Linux, and macOS.

Active terminal queries

0.3 adds explicit typed terminal interrogation to TerminalSession. Opening a session does not send DA, DSR, CPR, DECRQSS, XTGETTCAP, or any other probe.

A caller chooses which requests to issue and supplies the caller-visible timeout:

TimeSpan timeout = TimeSpan.FromMilliseconds( 750 );

TerminalPrimaryDeviceAttributes primary =
	await session.QueryPrimaryDeviceAttributesAsync( timeout );

TerminalCursorPosition cursor =
	await session.QueryCursorPositionAsync( timeout );

TerminalStatusStringResponse sgr =
	await session.QueryStatusStringAsync(
		TerminalStatusStringKind.SelectGraphicRendition,
		timeout
	);

TerminalCapabilityObservation terminalName =
	await session.QueryLiveCapabilityAsync(
		"TN",
		timeout
	);

The public query families are:

• Primary Device Attributes;
• Secondary Device Attributes;
• standard ECMA-48 Device Status Report;
• standard Cursor Position Report;
• fixed DECRQSS status-string requests;
• single-name XTGETTCAP live capability observations.

CPR rows and columns are one-based, matching the wire protocol. XTGETTCAP values remain exact decoded bytes because terminal capability values may contain ESC or other control bytes.

Caller cancellation uses ordinary OperationCanceledException semantics and a caller-visible deadline uses TimeoutException. Once request bytes have been emitted, the session retains bounded internal ownership long enough to consume or expire a late ambiguous response; a cancelled/timed-out query therefore cannot contaminate the next serialized query.

All responses are routed through the same session-owned input path used by ordinary text, keys, mouse, focus, paste, and lifecycle-aware event consumption. There is no public raw response reader or caller-extensible query protocol registration surface.

The reviewed 0.3 additions are recorded in docs/Public-API-Baseline-0.3.md.

Samples

The repository contains three deliberately different interactive samples:

• Icod.Terminal.Sample is the minimal session, identity, size, output, and restoration example;
• Icod.Terminal.RichInput.Sample is the 0.2 live event inspector for focus, bracketed paste, mouse input, modified keys, lifecycle events, and reversible input-protocol leases;
• Icod.Terminal.Query.Sample explicitly issues the 0.3 CSI/DCS query families while reversible presentation and rich-input leases are active, then returns to the unified event loop.

See samples/README.md for run instructions and expected behavior.

Build

On Windows:

build.cmd

On POSIX hosts:

sh build.sh

Both scripts support clean, restore, build, test, pack, and validate. Running either script without an argument performs the complete sequence, including Debug package validation.

Development roadmap

The completed 0.3.0 milestone is documented in Icod.Terminal-0.3.0-Development-Roadmap.md. The completed T21 foundation contract is recorded in docs/T21-0.3-Foundation-and-Contract-Reset.md. The completed T22 framing/demultiplexing tranche is recorded in docs/T22-Response-Framing-and-Single-Reader-Demultiplexing.md. The completed T23 transaction/lifetime tranche is recorded in docs/T23-Query-Transactions-Deadlines-and-Late-Response-Ownership.md. The completed T24 CSI query family is recorded in docs/T24-CSI-Query-Family.md. The completed T25 DECRQSS/DCS query tranche is recorded in docs/T25-DECRQSS.md. The completed T26 XTGETTCAP live-capability tranche is recorded in docs/T26-XTGETTCAP.md. The T27 integration and acceptance record is maintained in docs/T27-Query-Integration-and-Probe-Acceptance.md. The completed T28A release-candidate gate is recorded in docs/T28A-0.3-Release-Candidate-Gate.md, the stable T28B closure is recorded in docs/T28B-0.3.0-Release-Closure.md, and the reviewed 0.3 public API delta is published in docs/Public-API-Baseline-0.3.md. The completed 0.2.0 milestone remains in Icod.Terminal-0.2.0-Development-Roadmap.md.

See Icod.Terminal-Development-Roadmap.md for the architectural boundaries, 0.1.0 acceptance gates, and the path toward the stable 1.0.0 contract. The completed T02 extraction matrix is recorded in docs/T02-Extraction-Inventory-and-Contract-Classification.md, the T03 low-level contract is documented in docs/T03-Endpoint-Observation-and-Native-Mode-Parity.md, the T04 semantic mode contract is documented in docs/T04-Semantic-Input-Mode-Policy.md, the T05 session ownership contract is documented in docs/T05-TerminalSession-Lifecycle-and-Ownership.md, the T06 identity/output contract is documented in docs/T06-Terminal-Identity-TermInfo-and-Output-Setup.md, the T07 lifecycle contract is documented in docs/T07-Live-Dimensions-and-Lifecycle-Events.md, and the T08 input contract is documented in docs/T08-Input-Byte-Stream-and-Key-Event-Decoder.md.

The T09 presentation-lease contract is documented in docs/T09-Reversible-Terminal-Presentation-Leases.md. The T10 lifecycle-participant integration is recorded in docs/T10-DCurses-Lifecycle-Participant-Integration.md, the completed T11 ProcPs acceptance is recorded in docs/T11-ProcPs-Acceptance.md, the T12B public API/consumer review is recorded in docs/T12B-Public-API-and-Consumer-Contract.md, the completed T12C package gate is recorded in docs/T12C-Package-and-Fresh-Consumer-Validation.md, and final 0.1 release closure is recorded in docs/T12D-0.1.0-Release-Closure.md.

The 0.2 rich-input implementation is recorded tranche-by-tranche in T13-T19. The downstream acceptance result is in docs/T19-DCurses-Rich-Input-Acceptance.md, the reviewed 0.2 public API delta is in docs/Public-API-Baseline-0.2.md, the release-candidate gate is in docs/T20A-0.2-Release-Candidate-Gate.md, and stable release closure is recorded in docs/T20B-0.2.0-Release-Closure.md.

Authors

Inspired by original work from Bill Joy, author of the original termcap; Mary Ann (born Mark) Horton, author of terminfo; Pavel Curtis, author of pcurses; and Zeyd Ben-Halim, Eric S. Raymond, and Thomas Dickey, whose work developed and maintained libtinfo and ncurses.

Managed .NET implementation by Timothy J. Bruce uniblab@hotmail.com.

Copyright

Copyright (c) 2026 Timothy J. Bruce

License

Licensed under the GNU Lesser General Public License v3.0 or later. See LICENSE.
