Visualizer

A flexible framework for creating and managing custom visualizations.

Changelog · Contributing

Guide

Add one or more songs to visualize them. Reorder, drop new files onto the page, or remove tracks from the playlist panel (Shift + Tab), and switch between repeat-one, once, loop-all, and shuffle playback modes. Drop a .lrc file alongside a track to show synced lyrics, or let the configurator look them up online.

Open the configurator with Tab and the playlist with Shift + Tab. Use Space to play/pause, ←/→ to seek, Shift + ←/→ to switch tracks, and ↑/↓ to cycle visualizations. Focus a track's drag handle and use ↑/↓ to reorder it.

An AI splits every song into drums, bass, vocals, guitar, keys and the rest, so the visuals can follow each instrument. It runs on the graphics card and needs a browser with WebGPU. In the configurator's AI section, Stem separation turns it on or off, shows whether it is active, and picks the model (Shift + ↑/↓ cycles them). The Engine section's Smoothness shows how smoothly the page draws, and a warning on the main screen explains what to change when it can't keep up.

In the configurator's Layers section, every visualization lists the layers it is drawn from. Drag a layer to reorder it, lower its opacity to fade it out, or pick a blend mode to change how it mixes with the layers below. Your arrangement is remembered per visualization. The Lyrics layer on top and the Background layer at the bottom are added by the engine and stay in place; each visualization keeps its own settings for them, and its background can show an image you upload, with an optional effect (shake, beat pulse or parallax).

The system supports custom visualizations, which can be implemented by extending the Visualization class and declaring the layers it is drawn from with this.newLayer(). A visualization keeps the shared, per-frame state; each layer only paints its own part of the picture, and the engine takes care of clearing, background, lyrics, compositing, and isolating a failing layer from the rest.

Each visualization is one file in studio/view/visualizations/, imported from studio/view/visualizations.ts. The built-in ones serve as the reference for writing your own; CONTRIBUTING.md documents the whole API.

Below is an example of how to create and attach a custom visualization:

import "adaptive-extender/worker";
import { type Host } from "../../models/visualization.js";
import { Registry, Visualization } from "../../services/visualization-registry.js";

Registry.attach("My custom title", class extends Visualization {
	constructor() {
		super();
		// Layers are declared bottom to top; the engine adds the background and the lyrics itself.
		this.newLayer("Circle", this.#drawCircle.bind(this));
	}

	// Called on every frame, before any layer is painted. The context's transform is the camera.
	update(host: Host): void {
		const zoom = 1 + host.audioset.bassLevel * 0.1;
		host.context.scale(zoom, zoom);
	}

	// Everything in host is read-only except the context. The origin is the canvas centre.
	#drawCircle(host: Host): void {
		const { context, audioset } = host;
		context.beginPath();
		context.arc(0, 0, 100 * audioset.volume, 0, 2 * Math.PI);
		context.fillStyle = "white";
		context.fill();
	}
});
